Apollo™ 3020101 107T, 107T14 Rising Stem Gate Valve, 1/4 in Nominal, NPT End Style, 150 lb, Bronze Body, Hand Wheel Actuator, Domestic
CBPN:197631
UPC:670750655456
MPN:3020101
Price:
$75.14 / EA
Availability Information
Prop 65:
DESCRIPTION
Apollo™ Gate Valve, Rising Stem, Series: 107T, 1/4 in Nominal, NPT, 300 psi CWP/150 psi SWP, 150 lb, -20 to 406 deg F, 3 gpm, Full Port, Hand Wheel Actuator, 4.57 in Open Top to Inlet Center, Bronze Body, Brass/Bronze Trim, Grafoil®, 1.76 in L, Domestic
The Apollo™ Model 107T (30 Series) Gate Valve provides a cost effective "Made in the USA" alternative to globally sourced multi-turn valves. These valves are cast, machined, assembled, and tested in South Carolina. The Apollo™ gate valve is ideal for use in a wide variety of plumbing and heating applications including building service piping systems.
Apollo™ 3020101 107T, 107T14 Rising Stem Gate Valve, 1/4 in Nominal, NPT End Style, 150 lb, Bronze Body, Hand Wheel Actuator, Domestic
CBPN:197631
MPN:3020101
UPC:670750655456
Price:
$75.14 / EA
Availability Information
Prop 65:
DESCRIPTION
Apollo™ Gate Valve, Rising Stem, Series: 107T, 1/4 in Nominal, NPT, 300 psi CWP/150 psi SWP, 150 lb, -20 to 406 deg F, 3 gpm, Full Port, Hand Wheel Actuator, 4.57 in Open Top to Inlet Center, Bronze Body, Brass/Bronze Trim, Grafoil®, 1.76 in L, Domestic
The Apollo™ Model 107T (30 Series) Gate Valve provides a cost effective "Made in the USA" alternative to globally sourced multi-turn valves. These valves are cast, machined, assembled, and tested in South Carolina. The Apollo™ gate valve is ideal for use in a wide variety of plumbing and heating applications including building service piping systems.
Specifications
Brand: Apollo™
Body Material: Bronze
Domestic/Import: Domestic
End Style: NPT
Flow Rate: 3 gpm
Nominal Size: 1/4 in
Pressure Rating: 300 psi CWP/150 psi SWP
Series: 107T
Temperature Rating: -20 to 406 deg F
Type: Rising Stem
Actuator Type: Handwheel
Dimensions: 1.76 in L
Port Type: Full
Pressure Class: 150 lb
Softgoods Material: Grafoil®
Trim Material: Brass/Bronze
Top to Inlet Center: 4.57 in Open
Item Features
- Guided solid bronze disc wedge
- Adjustable graphite stem packing
- Dezincification resistant
- All bronze construction
- 100% factory tested
- Union bonnet
- Malleable iron rugged hand wheel
- Brass stem/bronze disc wedge
- Grafoil® packing
