Apollo™ 14-205-05

Apollo™ 14-205-05 14-200, 14205 Safety Relief Valve, 2 in, Male x Female, 8 psig, Bronze Body

CBPN:246977

UPC:670750498268

MPN:14-205-05

Price:
$473.75 / EA
Availability Information

DESCRIPTION

Apollo™ Safety Relief Valve, Series: 14-200, 2 in Nominal, Male x Female, 8 psig, 250 deg F, Bronze Body, Brass Trim, PTFE Coated EPDM O-Ring Softgoods, 7.12 in H

The Apollo® 14 series is a 100% American made bronze safety relief valve for protection of steam boilers, low pressure, high volume blowers, compressors and vacuum systems.

Apollo™ 14-205-05 14-200, 14205 Safety Relief Valve, 2 in, Male x Female, 8 psig, Bronze Body

CBPN:246977

MPN:14-205-05

UPC:670750498268

Price:
$473.75 / EA
Availability Information

Apollo Valve Logo

DESCRIPTION

Apollo™ Safety Relief Valve, Series: 14-200, 2 in Nominal, Male x Female, 8 psig, 250 deg F, Bronze Body, Brass Trim, PTFE Coated EPDM O-Ring Softgoods, 7.12 in H

The Apollo® 14 series is a 100% American made bronze safety relief valve for protection of steam boilers, low pressure, high volume blowers, compressors and vacuum systems.

Specifications

BrandApollo™
Body MaterialBronze
End StyleMNPT x FNPT
Nominal Size2 in
Pressure Rating8 psig
Series14-200
Temperature Rating250 deg F
Dimensions7.12 in H
Set Pressure8 psig
Softgoods MaterialPTFE Coated EPDM O-Ring
Trim MaterialBrass
Weight8.4 lbs

Item Features

  • One piece body, all bronze construction
  • Rust proofed steel spring
  • Chrome plated seat, PTFE coated disc
  • PTFE coated EPDM o-ring for positive seal
  • 3/8 in NPT side tapping for drain connection
  • Valves are capacity certified by the National board at 15 psig only, in accordance with ASME boiler and pressure vessel code section IV
  • Registered in all Canadian provinces and territories, CRN No. 0G8547.5C
