Apollo™ 14-205-03 14-200, 14205 Safety Relief Valve, 2 in, Male x Female, 5 psig, Bronze Body
CBPN:246975
UPC:670750498244
MPN:14-205-03
Price:
$451.19Â /Â ea
Availability Information
DESCRIPTION
Apollo™ Safety Relief Valve, Series: 14-200, 2 in Nominal, Male x Female, 5 psig, 250 deg F, Bronze Body, Brass Trim, PTFE Coated EPDM O-Ring Softgoods, 7.12 in H
The Apollo® 14 series is a 100% American made bronze safety relief valve for protection of steam boilers, low pressure, high volume blowers, compressors and vacuum systems.
Apollo™ 14-205-03 14-200, 14205 Safety Relief Valve, 2 in, Male x Female, 5 psig, Bronze Body
CBPN:246975
MPN:14-205-03
UPC:670750498244
Price:
$451.19Â /Â ea
Availability Information
Â
DESCRIPTION
Apollo™ Safety Relief Valve, Series: 14-200, 2 in Nominal, Male x Female, 5 psig, 250 deg F, Bronze Body, Brass Trim, PTFE Coated EPDM O-Ring Softgoods, 7.12 in H
The Apollo® 14 series is a 100% American made bronze safety relief valve for protection of steam boilers, low pressure, high volume blowers, compressors and vacuum systems.
Specifications
Brand: Apollo™
Body Material:Â Bronze
End Style:Â MNPT x FNPT
Nominal Size:Â 2 in
Pressure Rating:Â 5 psig
Series:Â 14-200
Temperature Rating:Â 250 deg F
Dimensions:Â 7.12 in H
Set Pressure:Â 5 psig
Softgoods Material:Â PTFE Coated EPDM O-Ring
Trim Material:Â Brass
Item Features
- One piece body, all bronze construction
- Rust proofed steel spring
- Chrome plated seat, PTFE coated disc
- PTFE coated EPDM o-ring for positive seal
- 3/8 in NPT side tapping for drain connection
- Valves are capacity certified by the National board at 15 psig only, in accordance with ASME boiler and pressure vessel code section IV
- Registered in all Canadian provinces and territories, CRN No. 0G8547.5C
