Apollo™ 10-604-36 10-600, RVW60 Safety Relief Valve, 3/4 in Nominal, FNPT End Style, 160 psig Pressure, Bronze Body, Domestic
CBPN:246748
UPC:670750878626
MPN:10-604-36
Price:
$145.18Â /Â ea
Availability Information
DESCRIPTION
Apollo™ Safety Relief Valve, Series: 10-600, 3/4 in Nominal, FNPT, 160 psig, 250 deg F, Media: Water, Lift Handle Actuator, Bronze Body, Silicon Seat, 3.2 in W x 5.3 in H, Domestic
High-capacity heating system valves with female inlet and standard or expanded female outlet. Elevated seat for drainage of water away from seat area. Entire pressure range is National Board capacity certified.
Apollo™ 10-604-36 10-600, RVW60 Safety Relief Valve, 3/4 in Nominal, FNPT End Style, 160 psig Pressure, Bronze Body, Domestic
CBPN:246748
MPN:10-604-36
UPC:670750878626
Price:
$145.18Â /Â ea
Availability Information
Â
DESCRIPTION
Apollo™ Safety Relief Valve, Series: 10-600, 3/4 in Nominal, FNPT, 160 psig, 250 deg F, Media: Water, Lift Handle Actuator, Bronze Body, Silicon Seat, 3.2 in W x 5.3 in H, Domestic
High-capacity heating system valves with female inlet and standard or expanded female outlet. Elevated seat for drainage of water away from seat area. Entire pressure range is National Board capacity certified.
Specifications
Brand: Apollo™
Body Material:Â Bronze
Domestic/Import:Â Domestic
End Style:Â FNPT
Nominal Size:Â 3/4 in
Pressure Rating:Â 160 psig
Series:Â 10-600
Temperature Rating:Â 250 deg F
Actuator Type:Â Lift Handle
Dimensions:Â 3.2 in W x 5.3 in H
Media:Â Water
Set Pressure:Â 160 psig
Softgoods Material:Â Silicon Seat
Item Features
- High Btu capacity rating
- Spring cage
- Protects against excessive water pressure due to failure of controls to regulate Btu input
- Corrosion resistant construction
- Fabric reinforced molded diaphragm isolates spring from water at all times
- ASME HV rating - 90% of actual capacity at 10% overpressure
- Standard outlet
