ALOYCO 374C02010 FIG 374 Swing Check Valve, 1" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Cover
CBPN: 248426
MPN:374C02010
Price:
$569.38 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 374, 1 in Nominal, Socket Weld, 150 lb, CF3M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
ALOYCO 374C02010 FIG 374 Swing Check Valve, 1" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Cover
CBPN: 248426
MPN:374C02010
Price:
$569.38 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 374, 1 in Nominal, Socket Weld, 150 lb, CF3M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 5.5 lbs
Nominal Size: 1 in
End Style: Socket Weld
Pressure Class: 150 lb
Softgoods Material: PTFE
Body Material: Stainless Steel
Inlet to Outlet Length: 4.53 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 3.1 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Integral Seat
- Recessed Retained Gasket
- API Trim 10 (316 SS)
- Bolted Cover
