ALOYCO 117FC02014 FIG 117 Gate Valve, 1-1/2" Nominal, Flanged End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Flexible Wedge Disc
CBPN: 117364
MPN:117FC02014
Price:
$511.02 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 117, 1-1/2 in Nominal, Flanged, 150 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
**This item may be subject to a minimum order quantity.**
ALOYCO 117FC02014 FIG 117 Gate Valve, 1-1/2" Nominal, Flanged End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Flexible Wedge Disc
CBPN: 117364
MPN:117FC02014
Price:
$511.02 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 117, 1-1/2 in Nominal, Flanged, 150 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 18 lbs
Nominal Size: 1-1/2 in
End Style: Flanged
Pressure Class: 150 lb
Body Material: Stainless Steel
Softgoods Material: PTFE
Actuator Type: Handwheel
Hand Wheel Diameter: 5.5 in
Inlet to Outlet Length: 6.5 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 11 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34, API 603
Item Features
- Solid Wedge Disc (1/2 - 1")
- Flexible Wedge Disc (1-1/2 - 24")
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
