ALOYCO 114SC02006 FIG 114 Gate Valve, 3/4" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Solid Wedge Disc
CBPN: 248503
MPN:114SC02006
Price:
/ EA
DESCRIPTION
ALOYCO Gate Valve, Figure 114, 3/4 in Nominal, Socket Weld, 150 lb, OS&Y, Raised Face, CF3M Stainless Steel Body, Bolted Bonnet, Rising Stem, Solid Wedge Disc
**This item may be subject to a minimum order quantity.**
ALOYCO 114SC02006 FIG 114 Gate Valve, 3/4" Nominal, Socket Weld End Style, 150 lb, Stainless Steel Body, Bolted Bonnet, Solid Wedge Disc
CBPN: 248503
MPN:114SC02006
Price:
/ EA
DESCRIPTION
ALOYCO Gate Valve, Figure 114, 3/4 in Nominal, Socket Weld, 150 lb, OS&Y, Raised Face, CF3M Stainless Steel Body, Bolted Bonnet, Rising Stem, Solid Wedge Disc
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 7.2 lbs
Nominal Size: 3/4 in
End Style: Socket Weld
Pressure Class: 150 lb
Body Material: Stainless Steel
Softgoods Material: PTFE
Actuator Type: Handwheel
Hand Wheel Diameter: 3.9 in
Inlet to Outlet Length: 3.15 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 8.5 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34, API 603
Item Features
- Solid Wedge Disc (1/2 - 1")
- Flexible Wedge Disc (1-1/2 - 2")
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
