Spears® 4732L2-012 True Union 2000 3-Way Vertical Diverter Ball Valve, 1-1/4 in Nominal, Socket End Style, PVC Body, Double L Port, FKM Softgoods, Domestic
CBPN: 274330
UPC:054211938959
MPN:4732L2-012
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Vertical, Series: True Union 2000, 1-1/4 in Nominal, Socket, 235 psi, 140 deg F, Double L Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, FKM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Spears® 4732L2-012 True Union 2000 3-Way Vertical Diverter Ball Valve, 1-1/4 in Nominal, Socket End Style, PVC Body, Double L Port, FKM Softgoods, Domestic
CBPN: 274330
MPN:4732L2-012
UPC:054211938959
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Vertical, Series: True Union 2000, 1-1/4 in Nominal, Socket, 235 psi, 140 deg F, Double L Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, FKM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Specifications
Item Features
- Chemical and corrosion resistant PVC or CPVC construction
- Vertical 3-way or horizontal diverter design (no branch shut-off)
- L-port, Multi l-port and T-port ball configuration options
- Interchangeable with all true union 2000 Valves, mates with union 2000 pipe unions
- High impact polypropylene handle
- Built-in handle lockout
- Strong, buttress thread union nuts
- Spears® double O-Ring Safe-T-Shear® stem design
- Spears® Safe-T-Blocked® seal carrier
- Self adjusting PTFE floating seat design
- Fully serviceable, replaceable components
- Assembled with silicone-free, water soluble lubricant
- 3-13/16 in Dia handwheel
- FKM O-ring
