Bonomi 8P0178 Actuated Ball Valve

Bonomi 8P0178-3 2-Way Split Body Pneumatic Actuated Ball Valve, Spring Return, 3 in, Flanged, 150 lb, 316 Stainless Steel Body, Full Port, FKM/Graphoil/PTFE Softgoods, Import

CBPN: 229492

MPN:8P0178-3

Price:
$2830.53 / EA

DESCRIPTION

Bonomi North America Ball Valve Package, 2-Way Split Body, Series: 760005, 3 in Nominal, Flanged, 150 lb, -4 to 400 deg F, Full Port, Media: Water, 2.99 in Orifice, Pneumatic Spring Return Actuator, 316 Stainless Steel Ball, 7.99 in Inlet to Outlet Length, 15.47 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel/PTFE Trim, FKM/Graphoil/PTFE, 14.65 in L x 5.83 in W x 19.21 in H, Import

The 8P0178 series pneumatic actuator assembled package features the 760005 series Class 150, full port, stainless steel split body, ISO 5211 pad, double D stem, flanged ball valve. This valve is designed to ANSI 16.5, ANSI 16.10, and ANSI 16.34. It is also certified to API 607, 4th edition, API 6FA, and meets NACE MR 0175 and NACE MR 0103. The Valbia pneumatic actuator comes with a hard-anodized aluminum body, and powder coated end caps. In addition, all Valbia pneumatic actuators are standardly furnished with elevated temperature seals to 302 deg F. The patented side loaded limit stops never enter the piston chamber eliminating extra possible leak paths.

Bonomi 8P0178-3 2-Way Split Body Pneumatic Actuated Ball Valve, Spring Return, 3 in, Flanged, 150 lb, 316 Stainless Steel Body, Full Port, FKM/Graphoil/PTFE Softgoods, Import

CBPN: 229492

MPN:8P0178-3

Price:
$2830.53 / EA

Bonomi Valve logo

DESCRIPTION

Bonomi North America Ball Valve Package, 2-Way Split Body, Series: 760005, 3 in Nominal, Flanged, 150 lb, -4 to 400 deg F, Full Port, Media: Water, 2.99 in Orifice, Pneumatic Spring Return Actuator, 316 Stainless Steel Ball, 7.99 in Inlet to Outlet Length, 15.47 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel/PTFE Trim, FKM/Graphoil/PTFE, 14.65 in L x 5.83 in W x 19.21 in H, Import

The 8P0178 series pneumatic actuator assembled package features the 760005 series Class 150, full port, stainless steel split body, ISO 5211 pad, double D stem, flanged ball valve. This valve is designed to ANSI 16.5, ANSI 16.10, and ANSI 16.34. It is also certified to API 607, 4th edition, API 6FA, and meets NACE MR 0175 and NACE MR 0103. The Valbia pneumatic actuator comes with a hard-anodized aluminum body, and powder coated end caps. In addition, all Valbia pneumatic actuators are standardly furnished with elevated temperature seals to 302 deg F. The patented side loaded limit stops never enter the piston chamber eliminating extra possible leak paths.

Specifications

BrandBonomi North America
Weight77.2 lbs
Nominal Size3 in
End StyleANSI 150 Flange
Pressure Class150 lb
Body Material316 Stainless Steel
Actuator TypePneumatic Spring Return
Ball Material316 Stainless Steel
Dimensions14.65 in L x 5.83 in W x 19.21 in H
Inlet to Outlet Length7.99 in
Manufacturer NameBonomi North America
MediaWater
Orifice Size2.99 in
Port TypeFull
Series760005
Softgoods MaterialFKM/Graphoil/PTFE
Temperature Rating-4 to 400 deg F
Top to Inlet Center15.47 in
Trim Material316 Stainless Steel/PTFE
Type2-Way Split Body
Warranty1 Year
Domestic/ImportImport
Country of OriginIT
Standards and ApprovalsANSI B16.5/B16.10/B16.34 | ASTM A351 Grade CF8M Body | ASTM A351/A479 Grade CF8M Ball | ASTM A479 Stem | Fire-Safe API 6FA-607 4th Edition | PED 97/23/CE | CSA Approved

Item Features

  • Blow out proof stem, adjustable stem packing
  • PTFE seats, packing and thrust washer
  • 100% tested
  • Antistatic device
  • 316 stainless steel stem
  • PTFE seal/stem seal
  • Graphoil seal/stem seal
  • FKM O-ring
