Apollo™ 1060517 10-600 Safety Relief Valve, 1 in Nominal, FNPT End Style, 85 psi Pressure, Bronze Body, Domestic
CBPN:246756
UPC:670750878756
MPN:10-605-17
Price:
$316.80 / EA
Prop 65:
DESCRIPTION
Apollo™, 1060517, Safety Relief Valve, Series: 10-600, 1 in Nominal, FNPT End Style, 85 psi Pressure, 250 deg F, Media: Water, Lift Lever Handle Actuator, Bronze Body, Silicone Seat Softgoods, 4 in W x 6.7 in H Dimensions, Domestic
High-capacity heating system valves with female inlet and standard or expanded female outlet. Elevated seat for drainage of water away from seat area. Entire pressure range is National Board capacity certified.
Apollo™ 1060517 10-600 Safety Relief Valve, 1 in Nominal, FNPT End Style, 85 psi Pressure, Bronze Body, Domestic
CBPN:246756
MPN:10-605-17
UPC:670750878756
Price:
$316.80 / EA
Prop 65:
DESCRIPTION
Apollo™, 1060517, Safety Relief Valve, Series: 10-600, 1 in Nominal, FNPT End Style, 85 psi Pressure, 250 deg F, Media: Water, Lift Lever Handle Actuator, Bronze Body, Silicone Seat Softgoods, 4 in W x 6.7 in H Dimensions, Domestic
High-capacity heating system valves with female inlet and standard or expanded female outlet. Elevated seat for drainage of water away from seat area. Entire pressure range is National Board capacity certified.
Specifications
Brand: Apollo™
Weight: 4.1 lbs
Nominal Size: 1 in
End Style: FNPT
Set Pressure: 85 psig
Body Material: Bronze
Actuator Type: Lift Lever Handle
Dimensions: 4 in W x 6.7 in H
Manufacturer Name: Apollo Conbraco
Media: Water
Pressure Rating: 85 psi
Series: 10-600
Softgoods Material: Silicone Seat
Temperature Rating: 250 deg F
Application: Protection Hot Water Heating Boilers and Hot Water Supply Systems
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: AISI 12L14 Spring Washer | ASME Section IV Heating Boilers | ASTM B584 Body | CE Marked | CRN 0G8547.5C | NB Certified | Pressure Equipment Directive 2014/68/EU (PED) | PROP65: Cancer and Reproductive Harm
Item Features
- High Btu capacity rating
- Spring cage
- Protects against excessive water pressure due to failure of controls to regulate Btu input
- Corrosion resistant construction
- Fabric reinforced molded diaphragm isolates spring from water at all times
- ASME HV rating - 90% of actual capacity at 10% overpressure
- Standard outlet
