ALOYCO 2117FC02060 FIG 2117 Gate Valve, 6" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Flexible Wedge Disc
CBPN: 265825
MPN:2117FC02060
Price:
$13221.22 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
DESCRIPTION
ALOYCO Gate Valve, Figure 2117, 6 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
ALOYCO 2117FC02060 FIG 2117 Gate Valve, 6" Nominal, Flanged End Style, 300 lb, Stainless Steel Body, Bolted Bonnet, Flexible Wedge Disc
CBPN: 265825
MPN:2117FC02060
Price:
$13221.22 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
DESCRIPTION
ALOYCO Gate Valve, Figure 2117, 6 in Nominal, Flanged, 300 lb, OS&Y, Raised Face, CF8M Stainless Steel Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
Specifications
Brand: Aloyco®
Weight: 224.8 lbs
Nominal Size: 6 in
End Style: Flanged
Pressure Class: 300 lb
Body Material: Stainless Steel
Softgoods Material: PTFE
Actuator Type: Handwheel
Hand Wheel Diameter: 14 in
Inlet to Outlet Length: 15.9 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 29.8 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Solid Wedge Disc (1/2 - 2")
- Flexible Wedge Disc (2-1/2 - 24")
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 10 (316 SS)
- Recessed Retained Gasket
