Spears® 867-575CSR Clamp-On Pipe Saddle, 8 x 1 in Nominal, Special Reinforced FNPT Connection, 4 in Dia Hole, CPVC, EPDM O-Ring, SCH 80/XH Domestic
CBPN:236235
UPC:054211404072
MPN:867-575CSR
Price:
$489.74 / EA
DESCRIPTION
Spears® Pipe Saddle, Clamp-On, 8 x 1 in Nominal, Special Reinforced FNPT Connection, 4 in Diameter Hole, SCH 80/XH Schedule, 150 psi Pressure, 73 deg F, Zinc Bolt, CPVC Clamp, 10-1/8 in W Dimensions, Gray, Domestic/Import: Domestic
Spears® 867-575CSR Clamp-On Pipe Saddle, 8 x 1 in Nominal, Special Reinforced FNPT Connection, 4 in Dia Hole, CPVC, EPDM O-Ring, SCH 80/XH Domestic
CBPN:236235
MPN:867-575CSR
UPC:054211404072
Price:
$489.74 / EA
DESCRIPTION
Spears® Pipe Saddle, Clamp-On, 8 x 1 in Nominal, Special Reinforced FNPT Connection, 4 in Diameter Hole, SCH 80/XH Schedule, 150 psi Pressure, 73 deg F, Zinc Bolt, CPVC Clamp, 10-1/8 in W Dimensions, Gray, Domestic/Import: Domestic
Specifications
Brand: Spears®
Weight: 10.39 lbs
Nominal Size: 8 x 1 in
Connection Type: Special Reinforced FNPT
Clamp Material: CPVC
Schedule Rating: SCH 80/XH
Bolt Material: Zinc
Color: Gray
Dimensions: 10-1/8 in W
Hole Diameter: 4 in
Manufacturer Name: Spears Manufacturing
Pressure Rating: 150 psi
Temperature Rating: 73 deg F
Type: Clamp-On
Domestic/Import: Domestic
Country of Origin: US
Item Features
- 4 in hole
- 4 in Dia hole saw
- EPDM O-ring seal and zinc plated hardware
- Molded CPVC
