Apollo™ 94VLF10401A 94VLF-A 2-Piece Ball Valve, 3/4 in Nominal, Press End Style, Lead Free Brass Body, Full Port, EPDM/PTFE Softgoods, Domestic
CBPN:204380
UPC:670750747823
MPN:94VLF10401A
Price:
$91.33 / EA
Prop 65:
Enter in multiples of 10
DESCRIPTION
Apollo™ 94VLF10401A, Ball Valve, 2-Piece, Series: 94VLF-A, 3/4 in Nominal, Press End Style, 250 psi Pressure, 0 to 250 deg F, Full Port, Media: Water, Handle Actuator, Chrome Plated Brass Ball, 3.85 in Inlet to Outlet Length, 1.92 in Top to Inlet Center, PTFE/Brass Trim, EPDM/PTFE Softgoods, Domestic
The Conbraco International™ 94VLF-A Series Lead Free Two-Piece Press Ball Valve is ideal for installation in most plumbing and heating systems, including potable water.
Apollo™ 94VLF10401A 94VLF-A 2-Piece Ball Valve, 3/4 in Nominal, Press End Style, Lead Free Brass Body, Full Port, EPDM/PTFE Softgoods, Domestic
CBPN:204380
MPN:94VLF10401A
UPC:670750747823
Price:
$91.33 / EA
Prop 65:
Enter in multiples of 10
DESCRIPTION
Apollo™ 94VLF10401A, Ball Valve, 2-Piece, Series: 94VLF-A, 3/4 in Nominal, Press End Style, 250 psi Pressure, 0 to 250 deg F, Full Port, Media: Water, Handle Actuator, Chrome Plated Brass Ball, 3.85 in Inlet to Outlet Length, 1.92 in Top to Inlet Center, PTFE/Brass Trim, EPDM/PTFE Softgoods, Domestic
The Conbraco International™ 94VLF-A Series Lead Free Two-Piece Press Ball Valve is ideal for installation in most plumbing and heating systems, including potable water.
Specifications
Brand: Apollo™
Weight: 0.81 lbs
Nominal Size: 3/4 in
End Style: Press
Pressure Rating: 250 psi
Body Material: Lead Free Brass
Port Type: Full
Softgoods Material: EPDM/PTFE
Actuator Type: Handle
Ball Material: Chrome Plated Brass
Inlet to Outlet Length: 3.85 in
Manufacturer Name: Apollo Conbraco
Media: Water
Series: 94VLF-A
Temperature Rating: 0 to 250 deg F
Top to Inlet Center: 1.92 in
Trim Material: PTFE/Brass
Type: 2-Piece
Application: Plumbing, Heating System and Potable Water
Warranty: 2 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: IAPMO/ANSI Z1157 | Federal Public Law 111-380 | MSS SP-110 | NSF/ANSI 61/372 | PROP65: Cancer and Reproductive Harm
Item Features
- Adjustable stem packing
- Leak before Press feature
- Corrosion resistant materials
- 100% factory tested
- Ridgid XL press tool compatible
- Steel plated insulated polyvinyl handle
- PTFE seat/brass stem
- EPDM O-ring seal/PTFE stem packing
- The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
