Apollo™ Apollo International™ 94ALF20701A 94ALF-A 2-Piece Ball Valve, 1-1/2 in Nominal, Solder End Style, Lead Free Brass Body, Full Port, PTFE Softgoods, UL/FM Approved
CBPN:182226
UPC:670750968334
MPN:94ALF-207-01A
Price:
$162.46 / EA
Prop 65:
Enter in multiples of 9
DESCRIPTION
Apollo™ 94ALF20701A, Ball Valve, 2-Piece, Series: 94ALF-A, 1-1/2 in Nominal, Solder End Style, 600 psi CWP Pressure, 0 to 400 deg F, Full Port, Media: Gas/Fuel/Water, Lever Operated Actuator, 316 Stainless Steel Ball, 4.43 in Inlet to Outlet Length, 3.17 in Top to Inlet Center, Brass Stem and PTFE Seat Trim
The Apollo™ International® 94ALF-A Lead Free forged brass ball valves combine reliable operation with maximum economy. Now with multi-agency approvals, the 94ALF-A is ideal for gas, fuels, fire protection and general plumbing and HVAC applications including potable water. Valves are ANSI 3rd party Lead Free certified.
Apollo™ Apollo International™ 94ALF20701A 94ALF-A 2-Piece Ball Valve, 1-1/2 in Nominal, Solder End Style, Lead Free Brass Body, Full Port, PTFE Softgoods, UL/FM Approved
CBPN:182226
MPN:94ALF-207-01A
UPC:670750968334
Price:
$162.46 / EA
Prop 65:
Enter in multiples of 9
DESCRIPTION
Apollo™ 94ALF20701A, Ball Valve, 2-Piece, Series: 94ALF-A, 1-1/2 in Nominal, Solder End Style, 600 psi CWP Pressure, 0 to 400 deg F, Full Port, Media: Gas/Fuel/Water, Lever Operated Actuator, 316 Stainless Steel Ball, 4.43 in Inlet to Outlet Length, 3.17 in Top to Inlet Center, Brass Stem and PTFE Seat Trim
The Apollo™ International® 94ALF-A Lead Free forged brass ball valves combine reliable operation with maximum economy. Now with multi-agency approvals, the 94ALF-A is ideal for gas, fuels, fire protection and general plumbing and HVAC applications including potable water. Valves are ANSI 3rd party Lead Free certified.
Specifications
Brand: Apollo™
Weight: 2.17 lbs
Nominal Size: 1-1/2 in
End Style: Solder
Pressure Rating: 600 psi CWP
Body Material: Lead Free Brass
Port Type: Full
Softgoods Material: PTFE
Actuator Type: Lever Operated
Ball Material: 316 Stainless Steel
Inlet to Outlet Length: 4.43 in
Manufacturer Name: Apollo Conbraco
Media: Gas/Fuel/Water
Series: 94ALF-A
Temperature Rating: 0 to 400 deg F
Top to Inlet Center: 3.17 in
Trim Material: Brass Stem and PTFE Seat
Type: 2-Piece
Application: Ideal for Gas, Fuels, Fire Protection, General Plumbing and HVAC
Warranty: 2 Years
Standards and Approvals: IAPMO IGC 157 | FM Approved | Lead-Free Compliant | MSS SP-110 | NSF/ANSI 61-8 Annex F and G | NSF/ANSI 372 Lead-Free | UL YQNZ/YRBX/YRPV/YSDT/MHKZ | PROP65: Cancer and Reproductive Harm
Item Features
- Blow-out proof stem
- Distinctive white Lead free handle grip and blue Lead free hang tag
- Adjustable stem packing nut
- Multiple agency approvals
- Lead free brass (DZR) retainer
- UNS C37700 brass gland nut
- Steel, plated (with PVC grip) handle
- Plated steel handle nut
- Lead free chrome plated brass ball
