Apollo™ 87A20G24MG 87A-200 Ball Valve, 10 in Nominal, Flanged End Style, 150 lb, Full Port, Graphite/PTFE Softgoods, Domestic
CBPN:245540
UPC:670750305627
MPN:87A-20G-24-MG
Price:
$29113.51 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
Prop 65:
DESCRIPTION
Apollo™ 87A20G24MG, Ball Valve, Series: 87A-200, 10 in Nominal, Raised Face Flanged End Style, 150 lb Pressure Class, Full Port, Gear with Handwheel Actuator, Stainless Steel Ball, 21 in Inlet to Outlet Length, 18.57 in Top to Inlet Center, 316 Stainless Steel/RPTFE Trim, Graphite/PTFE Softgoods, Domestic
Apollo™ 87A20G24MG 87A-200 Ball Valve, 10 in Nominal, Flanged End Style, 150 lb, Full Port, Graphite/PTFE Softgoods, Domestic
CBPN:245540
MPN:87A-20G-24-MG
UPC:670750305627
Price:
$29113.51 / EA
Oversize or overweight
This item cannot ship via small package carrier, such as UPS or FedEx Ground. Delivery options will be available at checkout.
Prop 65:
DESCRIPTION
Apollo™ 87A20G24MG, Ball Valve, Series: 87A-200, 10 in Nominal, Raised Face Flanged End Style, 150 lb Pressure Class, Full Port, Gear with Handwheel Actuator, Stainless Steel Ball, 21 in Inlet to Outlet Length, 18.57 in Top to Inlet Center, 316 Stainless Steel/RPTFE Trim, Graphite/PTFE Softgoods, Domestic
Specifications
Brand: Apollo™
Weight: 902 lbs
Nominal Size: 10 in
End Style: ANSI 150 Flange
Pressure Class: 150 lb
Body Material: Stainless Steel
Port Type: Full
Softgoods Material: Graphite/PTFE
Actuator Type: Gear with Handwheel
Ball Material: Stainless Steel
Inlet to Outlet Length: 21 in
Manufacturer Name: Apollo Conbraco
Series: 87A-200
Top to Inlet Center: 18.57 in
Trim Material: 316 Stainless Steel/RPTFE
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: API 608 | ASME B16.34 | ASTM A351 CF8M Body | ASTM A276 Stem/Ball | CSA ASME B16.33/B16.38 | MSS SP-25/SP-72 | NSF/ANSI 61 | UL Listed | PROP65: Cancer and Reproductive Harm
Item Features
- MG - gear operated, standard hand wheel
- 2-position locking device
- Chevron style adjustable stem seal bolt pattern
- Slot vented ball for thermal expansion
- Rated up to 150 psig saturated steam
- Anti-static grounded ball and stem
- Blow-out proof stem design
- Cast boss for bleed/drain port
- Vacuum service to 29 in Hg
