Apollo™ 6160401 61-600 Standard In-Line Soft Seat Check Valve, 3/4 in Nominal, Solder End Style, 4.78 gpm Flow Rate, Bronze Body, Domestic
CBPN:6861
UPC:670750632945
MPN:61-604-01
Price:
$121.05 / EA
Prop 65:
DESCRIPTION
Apollo™ 6160401, In-Line Soft Seat Check Valve, Standard, Series: 61-600, 3/4 in Nominal, Solder End Style, 400 psi CWP Pressure, 250 deg F, 4.78 gpm Flow Rate, 3.68 in Inlet to Outlet Length, Bronze Body, EPR/EPDM Rubber Seat/Stainless Steel Spring Trim, 1-1/2 in H Dimensions, Domestic
The Apollo™ CVBE soft seat check valves offer reliable tight shut-off protection against reverse flow and corrosion resistance using proven ASTM quality materials made in the USA.
Apollo™ 6160401 61-600 Standard In-Line Soft Seat Check Valve, 3/4 in Nominal, Solder End Style, 4.78 gpm Flow Rate, Bronze Body, Domestic
CBPN:6861
MPN:61-604-01
UPC:670750632945
Price:
$121.05 / EA
Prop 65:
DESCRIPTION
Apollo™ 6160401, In-Line Soft Seat Check Valve, Standard, Series: 61-600, 3/4 in Nominal, Solder End Style, 400 psi CWP Pressure, 250 deg F, 4.78 gpm Flow Rate, 3.68 in Inlet to Outlet Length, Bronze Body, EPR/EPDM Rubber Seat/Stainless Steel Spring Trim, 1-1/2 in H Dimensions, Domestic
The Apollo™ CVBE soft seat check valves offer reliable tight shut-off protection against reverse flow and corrosion resistance using proven ASTM quality materials made in the USA.
Specifications
Brand: Apollo™
Weight: 0.86 lbs
Nominal Size: 3/4 in
End Style: Solder
Flow Rate: 4.78 gpm
Body Material: Bronze
Actuator Type: Spring-Loaded Latch-Lock Handle
Dimensions: 1-1/2 in H
Inlet to Outlet Length: 3.68 in
Manufacturer Name: Apollo Conbraco
Pressure Rating: 400 psi CWP
Series: 61-600
Temperature Rating: 250 deg F
Trim Material: EPR/EPDM Rubber Seat/Stainless Steel Spring
Type: Standard
Application: Hydronic Heating and Other Low Flow Applications
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: AISI Spring | CRN 0C11218.5C | UNS C84400 Valve Body | PROP65: Cancer and Reproductive Harm
Item Features
- Resilient EPR soft seat
- Superior shut-off
- 0.5 psig cracking pressure
