ALOYCO 370C02006 FIG 370 Swing Check Valve, 3/4" Nominal, FNPT End Style, 150 lb, Stainless Steel Body, Bolted Cover
CBPN:71077
MPN:370C02006
Price:
$578.53 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 370, 3/4 in Nominal, FNPT, 150 lb, CF3M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
ALOYCO 370C02006 FIG 370 Swing Check Valve, 3/4" Nominal, FNPT End Style, 150 lb, Stainless Steel Body, Bolted Cover
CBPN:71077
MPN:370C02006
Price:
$578.53 / EA
DESCRIPTION
ALOYCO Swing Check Valve, Figure 370, 3/4 in Nominal, FNPT, 150 lb, CF3M Stainless Steel Body, Bolted Cover
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 3.7 lbs
Nominal Size: 3/4 in
End Style: FNPT
Pressure Class: 150 lb
Softgoods Material: PTFE
Body Material: Stainless Steel
Inlet to Outlet Length: 3.74 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 2.8 in
Trim Material: API Trim 10 (316SS)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34
Item Features
- Integral Seat
- Recessed Retained Gasket
- API Trim 10 (316 SS)
- Bolted Cover
