Spirax Sarco 0780292, KA 43 Direct Acting Temperature Regulator Valve, 1/2 in, ANSI 300 Flange, 17 bar
CBPN:239450
MPN:0780292
Price:
$1543.73 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Direct Acting, 1/2 in Nominal, ANSI 300 Flange, 17 bar, Carbon Steel Body, Stainless Steel Trim, 5.1 in L
Spirax Sarco 0780292, KA 43 Direct Acting Temperature Regulator Valve, 1/2 in, ANSI 300 Flange, 17 bar
CBPN:239450
MPN:0780292
Price:
$1543.73 / EA
DESCRIPTION
Spirax Sarco Temperature Regulator Valve, Direct Acting, 1/2 in Nominal, ANSI 300 Flange, 17 bar, Carbon Steel Body, Stainless Steel Trim, 5.1 in L
Specifications
Brand: Spirax Sarco
Weight: 9.5 lbs
Nominal Size: 1/2 in
End Style: ANSI 300 Flange
Pressure Rating: 17 bar
Body Material: Carbon Steel
Dimensions: 5.1 in L
Manufacturer Name: Spirax-Sarco Inc
Series: KA43
Trim Material: Stainless Steel
Type: Direct Acting
Application: Small process applications using steam or hot water as a heating medium
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ANSI Class IV Shut-Off | DIN 17245 GSC 25 Body
Item Features
- Maximum allowable temperature: 750 deg F at 0 to 188 psig
- 3.36 Cv
- 8 deg p-band
- Differential pressure: 250 psi
- 2-port
- Maximum allowable pressure: 362 psig at 248 deg F
- 3.2 mm stroke
- Horizontal installation
- Normally open, closes with rising temperature for heating
- Single seat
