Spears® 5022T1-040 True Union 2000 3-Way Horizontal Diverter Ball Valve, 4 in Nominal, Socket End Style, PVC Body, T-Port Port, FKM Softgoods, Domestic
CBPN:141159
UPC:054211911754
MPN:5022T1-040
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Horizontal, Series: True Union 2000, 4 in Nominal, Socket, 150 psi, 140 deg F, T-Port Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, FKM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Spears® 5022T1-040 True Union 2000 3-Way Horizontal Diverter Ball Valve, 4 in Nominal, Socket End Style, PVC Body, T-Port Port, FKM Softgoods, Domestic
CBPN:141159
MPN:5022T1-040
UPC:054211911754
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Horizontal, Series: True Union 2000, 4 in Nominal, Socket, 150 psi, 140 deg F, T-Port Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, FKM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Specifications
Item Features
- Chemical and corrosion resistant PVC or CPVC construction
- Vertical 3-way or horizontal diverter design (no branch shut-off)
- L-port, Multi l-port and T-port ball configuration options
- Interchangeable with all true union 2000 Valves, mates with union 2000 pipe unions
- Strong, buttress thread union nuts
- Spears® double O-Ring Safe-T-Shear® stem design
- Spears® Safe-T-Blocked® seal carrier
- Self adjusting PTFE floating seat design
- Fully serviceable, replaceable components
- Assembled with silicone-free, water soluble lubricant
- FKM O-ring
