Spears® 5021L1-040SR True Union 2000 3-Way Horizontal Diverter Ball Valve, 4 in Nominal, FNPT End Style, PVC Body, L-Port Port, EPDM Softgoods, Domestic
CBPN:274316
UPC:054211940402
MPN:5021L1-040SR
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Horizontal, Series: True Union 2000, 4 in Nominal, FNPT, 150 psi, 140 deg F, L-Port Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, EPDM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Spears® 5021L1-040SR True Union 2000 3-Way Horizontal Diverter Ball Valve, 4 in Nominal, FNPT End Style, PVC Body, L-Port Port, EPDM Softgoods, Domestic
CBPN:274316
MPN:5021L1-040SR
UPC:054211940402
DESCRIPTION
Spears® Diverter Ball Valve, 3-Way Horizontal, Series: True Union 2000, 4 in Nominal, FNPT, 150 psi, 140 deg F, L-Port Port, T-Handle Actuator, PVC Ball, PVC Body, PVC Stem Trim, EPDM, Gray, Domestic
Versatile design provides multiple port and configuration options for controlling flow distribution in industrial and chemical processing applications. Choose vertical 3-Way (L-Port Diverter, T-Port Off) or horizontal diverter configurations with open branch (no shut-off) design. Valves are available in IPS sizes 1/2 in through 4 in with socket, SR threaded (Special Reinforced), flanged or spigot end connectors. Ventured 6 in (4 in valves with 4 x 6 reducers) are also available with socket or flanged valve end connections.
Specifications
Item Features
- Chemical and corrosion resistant PVC or CPVC construction
- Vertical 3-way or horizontal diverter design (no branch shut-off)
- L-port, Multi l-port and T-port ball configuration options
- Interchangeable with all true union 2000 Valves, mates with union 2000 pipe unions
- Strong, buttress thread union nuts
- Spears® double O-Ring Safe-T-Shear® stem design
- Spears® Safe-T-Blocked® seal carrier
- Self adjusting PTFE floating seat design
- Fully serviceable, replaceable components
- Assembled with silicone-free, water soluble lubricant
- EPDM O-ring
