Gruvlok® Cross Clamp-T Branch Outlet, Series: FIG 7046, 5 x 3 in Nominal, Grooved, 500 psi, -40 to 230 deg F, 5/8 x 3-1/4 in Bolt, Steel Bolt, Ductile Iron Clamp, Grade E Gasket, 5.563 x 3.5 in OD x 9.125 in L x 5.25 in D, Orange, Rust Inhibiting Painted, Domestic

The Gruvlok® Clamp-T provides a quick and easy outlet at any location along the pipe. A hole drilled or cut in the pipe to receive the locating collar of the Clamp-T is all that is required. The full, smooth outlet area provides for optimum flow characteristics. The Clamp-T housing is specially engineered to conform to the pipe OD and the Clamp-T gasket providing a leak-tight reliable seal in both positive pressure and vacuum conditions. The maximum working pressure for all sizes is 500 psi (34.5 bar) when assembled on standard wall steel pipe.
