CRANE® 351-4 Globe Valve, 4 in Nominal, Flanged End Style, 125 lb, Cast Iron Body, Handwheel Actuator
CBPN:11970
MPN:351-4
Price:
$4529.32 / EA
DESCRIPTION
CRANE® Globe Valve, Series: 351, 4 in Nominal, Flanged End Style, 125 lb Pressure Class, Handwheel Actuator, 11-1/2 in Inlet to Outlet Length, 15-1/2 in Top to Inlet Center, Cast Iron Body, Bronze Trim, Braided Flexible Graphite with Corrosion Inhibitor Packing/Aramid Fiber with SBR Binder Bonnet Gasket Softgoods, 10 in Diameter Hand Wheel
CRANE® 351-4 Globe Valve, 4 in Nominal, Flanged End Style, 125 lb, Cast Iron Body, Handwheel Actuator
CBPN:11970
MPN:351-4
Price:
$4529.32 / EA
DESCRIPTION
CRANE® Globe Valve, Series: 351, 4 in Nominal, Flanged End Style, 125 lb Pressure Class, Handwheel Actuator, 11-1/2 in Inlet to Outlet Length, 15-1/2 in Top to Inlet Center, Cast Iron Body, Bronze Trim, Braided Flexible Graphite with Corrosion Inhibitor Packing/Aramid Fiber with SBR Binder Bonnet Gasket Softgoods, 10 in Diameter Hand Wheel
Specifications
Brand: CRANE®
Weight: 95 lbs
Nominal Size: 4 in
End Style: Flanged
Pressure Class: 125 lb
Body Material: Cast Iron
Actuator Type: Handwheel
Hand Wheel Diameter: 10 in
Inlet to Outlet Length: 11-1/2 in
Manufacturer Name: Crane ChemPharma Energy
Series: 351
Softgoods Material: Braided Flexible Graphite with Corrosion Inhibitor Packing/Aramid Fiber with SBR Binder Bonnet Gasket
Top to Inlet Center: 15-1/2 in
Trim Material: Bronze
Standards and Approvals: ASTM A126 Class B Body/Bonnet | ASTM A536 Grade 65-45-12 Handwheel | ASTM B584 C86400 Stem | MSS SP-85 | Type 1
Item Features
- Bolted Bonnet
- Outside stem and yoke
- Ductile iron handwheel
