Apollo™ 6160801 61-600 Standard In-Line Soft Seat Check Valve, 2 in Nominal, Solder End Style, 81 gpm Flow Rate, Bronze Body, Domestic
CBPN:87750
UPC:670750361364
MPN:61-608-01
Price:
$573.77 / EA
Prop 65:
DESCRIPTION
Apollo™ 6160801, In-Line Soft Seat Check Valve, Standard, Series: 61-600, 2 in Nominal, Solder End Style, 400 psi CWP Pressure, 250 deg F, 81 gpm Flow Rate, 7.46 in Inlet to Outlet Length, Bronze Body, EPR/EPDM Rubber Seat/Stainless Steel Spring Trim, 3.69 in H Dimensions, Domestic
The Apollo™ CVBE soft seat check valves offer reliable tight shut-off protection against reverse flow and corrosion resistance using proven ASTM quality materials made in the USA.
Apollo™ 6160801 61-600 Standard In-Line Soft Seat Check Valve, 2 in Nominal, Solder End Style, 81 gpm Flow Rate, Bronze Body, Domestic
CBPN:87750
MPN:61-608-01
UPC:670750361364
Price:
$573.77 / EA
Prop 65:
DESCRIPTION
Apollo™ 6160801, In-Line Soft Seat Check Valve, Standard, Series: 61-600, 2 in Nominal, Solder End Style, 400 psi CWP Pressure, 250 deg F, 81 gpm Flow Rate, 7.46 in Inlet to Outlet Length, Bronze Body, EPR/EPDM Rubber Seat/Stainless Steel Spring Trim, 3.69 in H Dimensions, Domestic
The Apollo™ CVBE soft seat check valves offer reliable tight shut-off protection against reverse flow and corrosion resistance using proven ASTM quality materials made in the USA.
Specifications
Brand: Apollo™
Weight: 6.3 lbs
Nominal Size: 2 in
End Style: Solder
Flow Rate: 81 gpm
Body Material: Bronze
Actuator Type: Spring-Loaded Latch-Lock Handle
Dimensions: 3.69 in H
Inlet to Outlet Length: 7.46 in
Manufacturer Name: Apollo Conbraco
Pressure Rating: 400 psi CWP
Series: 61-600
Temperature Rating: 250 deg F
Trim Material: EPR/EPDM Rubber Seat/Stainless Steel Spring
Type: Standard
Application: Hydronic Heating and Other Low Flow Applications
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: AISI Spring | CRN 0C11218.5C | UNS C84400 Valve Body | PROP65: Cancer and Reproductive Harm
Item Features
- Soft seat allows more resistance to vibration and may be installed in both horizontal and vertical upward flow applications
- Resilient EPR soft seat
- Superior shut-off
- 0.5 psig cracking pressure
- cast bronze construction
