Apollo™ 13214B15 13 Low Pressure Safety Relief Valve, 1-1/2 x 2 in Nominal, MNPT x FNPT End Style, 15 psi Pressure, Bronze Body, Domestic
CBPN:137892
UPC:670750221170
MPN:13-214-B-15
Price:
$255.50 / EA
Prop 65:
DESCRIPTION
Apollo™ 13214B15, Safety Relief Valve, Low Pressure, Series: 13, 1-1/2 x 2 in Nominal, MNPT x FNPT End Style, 15 psi Pressure, 250 deg F, Bronze Body, Brass Trim, TFE Seat Softgoods, 5-1/4 in H Dimensions, Domestic
The Apollo® 13 Series bronze low pressure steam safety valve is designed to meet ASME Section IV code requirements for protection of steam heating boilers, systems and similar equipment.
Apollo™ 13214B15 13 Low Pressure Safety Relief Valve, 1-1/2 x 2 in Nominal, MNPT x FNPT End Style, 15 psi Pressure, Bronze Body, Domestic
CBPN:137892
MPN:13-214-B-15
UPC:670750221170
Price:
$255.50 / EA
Prop 65:
DESCRIPTION
Apollo™ 13214B15, Safety Relief Valve, Low Pressure, Series: 13, 1-1/2 x 2 in Nominal, MNPT x FNPT End Style, 15 psi Pressure, 250 deg F, Bronze Body, Brass Trim, TFE Seat Softgoods, 5-1/4 in H Dimensions, Domestic
The Apollo® 13 Series bronze low pressure steam safety valve is designed to meet ASME Section IV code requirements for protection of steam heating boilers, systems and similar equipment.
Specifications
Brand: Apollo™
Weight: 3.2 lbs
Nominal Size: 1-1/2 x 2 in
End Style: MNPT x FNPT
Set Pressure: 15 psig
Body Material: Bronze
Trim Material: Brass
Dimensions: 5-1/4 in H
Manufacturer Name: Apollo Conbraco
Pressure Rating: 15 psi
Series: 13
Softgoods Material: TFE Seat
Temperature Rating: 250 deg F
Type: Low Pressure
Application: Steam Boiler
Warranty: 5 Years
Domestic/Import: Domestic
Country of Origin: US
Standards and Approvals: ASTM B584 Valve Body | ASME Section IV LP Steam Certified | CRN 0G8547.5C | PROP65: Cancer and Reproductive Harm
Item Features
- EPDM disc for positive seal
- Standard set pressure of 15 psi, capacities apply to valves set at 15 psi
- Stainless steel spring
- Corrosion resistant construction
- Compact design top outlet design option
- 1900 lb/hr capacity
