ALOYCO 117FC03020 FIG 117 Gate Valve, 2" Nominal, Flanged End Style, 150 lb, Alloy 20 Body, Bolted Bonnet, Flexible Wedge Disc
CBPN:265810
MPN:117FC03020
Price:
$5420.23 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 117, 2 in Nominal, Flanged, 150 lb, OS&Y, Raised Face, CN7M Alloy 20 Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
**This item may be subject to a minimum order quantity.**
ALOYCO 117FC03020 FIG 117 Gate Valve, 2" Nominal, Flanged End Style, 150 lb, Alloy 20 Body, Bolted Bonnet, Flexible Wedge Disc
CBPN:265810
MPN:117FC03020
Price:
$5420.23 / EA
DESCRIPTION
ALOYCO Gate Valve, Figure 117, 2 in Nominal, Flanged, 150 lb, OS&Y, Raised Face, CN7M Alloy 20 Body, Bolted Bonnet, Rising Stem, Flexible Wedge Disc
**This item may be subject to a minimum order quantity.**
Specifications
Brand: Aloyco®
Weight: 27 lbs
Nominal Size: 2 in
End Style: Flanged
Pressure Class: 150 lb
Body Material: Alloy 20
Softgoods Material: PTFE
Actuator Type: Handwheel
Hand Wheel Diameter: 6.3 in
Inlet to Outlet Length: 7 in
Manufacturer Name: Crane ChemPharma Energy
Top to Inlet Center: 12.6 in
Trim Material: API Trim 13 (Alloy 20)
Domestic/Import: Import
Country of Origin: CH
Standards and Approvals: MSS SP-42, ASME B16.34, API 603
Item Features
- Solid Wedge Disc (1/2 - 1")
- Flexible Wedge Disc (1-1/2 - 24")
- Bolted Bonnet
- Rising Stem
- Integral Seat
- Outside Stem & Yoke
- API Trim 13 (Alloy 20)
